Nominal diameter:PN10 DN200~3000
PN16 DN200~2600
PN25 DN200~2000
PN40 DN200~1200
Body Test Pressure:1.5 times rated pressure
Seat Test Pressure:1.1 times rated pressure
Working temperature:-10 ˚C ~+130 ˚C
Design standard Conform To | EN 593 |
Connection flange conform To | EN1092-2, ISO7005-2 |
Top flange conform to | ISO 5211 |
Face to face conform to | EN 558 Series 14 |
Test standard conform to | EN12266-1 |
Nominal working pressure | PN10/PN16/PN25/PN40 |
Nominal diameter:PN10 DN200~3000
PN16 DN200~2600
PN25 DN200~2000
PN40 DN200~1200
Body Test Pressure:1.5 times rated pressure
Seat Test Pressure:1.1 times rated pressure
Working temperature:-10 ˚C ~+130 ˚C
